Specifications
Key Features
- 13 Digits Vertical Alignment LCD
- Front USB & AUX input
- Android Music Playback
- 3 Band parametric equalizer
- flac playback (48kHz - 16bit)
- White Display & Red Key Illumination
- USB 1A Charge Capability for Smartphone
- Less than 1mA Dark Current Consumption
- 2 RCA Preout, 2,5V level
- Rear/Subwoofer Switchable
General Features
- DIN Size: 1 DIN
- Detachable Faceplate
- Key Illumination: Red LED
- Rotary Encoder & Control Knob
- Accent key: Audio Control
- Back-up Memory: Only Tuner Presets
- Touch Sensor Tone
- Digital Clock (24H)
- All-off Select (20/40/60 minutes)
- ISO connector, New Mitsumi to ISO cable
- USB interface x 1
- Firmware upgreadable
Display Features
- Display Type: Liquid Crystal Display (LCD)
- Display Layout: 13 Segments x 13 Digit
- Vertical Aligment Liquid Crystal Display
- Display Illumination: White LED
- Dimmer Control: Manual / Set by Timer
- Brightness control: 0 - 31 steps
- Demo Mode
- Menu text in selectable language: English, Spanish, Russian
- TAG Language Display: English, Spanish, Russian & Greek
Cosmetics features
- Front/edge: Black Injection
- Volume & operation knob or wheel: Chrome-finished
- Escutcheon finish: Black Injection
- Triangle Illumination: Red
- Key illumination: Red LED
- Display illumination: White LED
- Brightness Control (Key): 0 - 31 step
- Brightness Control (Display): 0 - 31 step
- Dimmer Control (Key): Manual / Set by Timer
- Dimmer Control (Display): Manual / Set by Timer
Tuner Features
- FM Reception
- AM (MW/LW) Reception
- Tuner Presets (FM/AM): 24 Presets (18FM / 6AM)
- Preset memory w/o back-up power
- Mixed preset memory (FM & AM): 6 presets
- Tuning mode:
- Up/Down Seek/Scan
- Automatic Memory Entry (AME)
- FM Stereo / Mono Selector
- Radio Data System
- Radio Text Plus
- Traffic Information
- Local search
- Auto TP search
- Enhanced Other Networks Function (EON)
- Program Type Function (PTY)
- PTY News: Off/0/10/20/.../80/90min
CE_Playable Audio file
- MP3 files are playable: CD/USB
- WMA (.wma) files are playable: CD/USB
- WAV (.wav) files are playable: USB
- FLAC files are playable: USB
CD Features
- CD-R/RW Compatible
- MP3 Playback with ID3 Tag Display
- WMA (Windows Media Audio) Playback
- CD Text with special Character Support: English, Spanish, Russian & Greek
- D.A.C. processing: 16 bit
- 0 bit Mute
- Random Function
- Repeat Function
- Scan Function
USB Features
- USB terminal, Front USB 2.0 (Full Speed)
- Android USB Mass Storage Class (MSC)
- Android Open Accessory support (AOA): V 2.0
- MP3, WMA, WAV, FLAC playback
- Repeat / Random Play
- Direct search
- Time code display
- 1A Charge Capability for Smartphone.
Audio Features
- Maximum Output Power: 50W x 4
- MOSFET Power IC
- Auxiliary input: Front Mini-jack
- Pre-out: 1 RCA
- Pre-out Output Level: 2.5V
- Preout Rear / Subwoofer Switchable
- Subwoofer Reference Level Adj.
- Source Tone Control & Memory: Bass / Mid / Treble
- Tone Control / Easy EQ: 3-Band, 8 Presets
- Balance/Fader/Loudness Control
- Balance/Fader Control
- Loudness Control: Off/Low/High
- Bass Boost Circuit: Off/+1/+2/+3/+4/+5
- System Q (Preset Sound Control)
- Graphic Equalizer + Preset: 3-Bands Graphic Equalizer with 8 Presets.
- Low-pass Filter
- Kenwood Sound Reconstruction
- Drive EQ
Connectivity
- Front USB & AUX Input
- OEM Wired Remote Control ready
- DC-Cord: NEW Mitsumi to ISO
- Power Control (P.CON) wire
- FM Antenna Input
Tuner Specifications
- FM range: 87.5Mhz - 108MHz (50Khz step)
- FM Usable Sensitivity: 0.71μV/75ohm (S/N 26dB)
- FM Quieting Sensitivity: 2μV/75ohm (S/N 46dB)
- FM Frequency Response: 30Hz ~ 15kHz (± 3dB)
- FM Signal to noise ratio (Mono): 64dB
- FM Stereo Separation (1kHz): 40dB
- MW range: 531kHz - 1611kHz (9kHz step)
- MW Usable Sensitivity: 28.2μV
- LW range: 153kHz - 279kHz (9kHz step)
- LW Usable Sensitivity: 50μV
Codec Specs
- MP3 Format: MPEG 1/2 Audio Layer 3-Files
- WMA Format: Compliant with Windows Media Audio
- WAV Format: RIFF waveform Audio Format (only for LinearPCM)
- FLAC Format: FLAC files (up to 48kHz/16bit)
CD Specifications
- Laser Diode: GaAIAs
- Digital Filter(D/A): 8 Times Over Sampling
- Digital/Analogue Converter: 16 Bit
- Spindle Speed: 500 ~ 200rpm (CLV: 1 times)
- Wow & Flutter: Below Measurable Limit
- Frequency Response: 20Hz ~ 20kHz (±1dB)
- Total Harmonic Distortion: 0.01% (1kHz)
- Signal to Noise Ratio: 105dB (1kHz)
- Dynamic Range: 90dB
- Channel Separation: 85dB
- MP3 Decoder: Compliant with MPEG-1/2 Audio Layer-3
- WMA Decoder: Compliant with Windows Media Audio
USB Specifications
- USB Version compatibility: USB 1.1/2.0 full speed
- File System: FAT 32/16/12
- Maximum Supply current: 1500mA
- D/A Converter: 16 bit
- MP3 Decode: Compliant with MPEG-1/2 Audio Layer-3
- WMA Decode: Compliant with Windows Media Audio
- WAV Decode: Linear - PCM Files
- flac Decode: FLAC files up to 48kHz/16bit
Audio Specifications
- Maximum Power: 50W x 4
- Output Power (DIN45324,+B=14.4v): 22W x 4
- Preout Level: 2500mV / 10kOhm,
- Preout Impedance: ≤ 600Ohm
- Speaker Impedance: 4Ohm ~ 8Ohm
- AUX Frequency Response: 20Hz ~ 20kHz (±1dB)
- AUX Maximum Input Voltage: 1000mV
- AUX Input Impedance: 30kOhm
- G. EQ. Gain (dB): +/- 9dB
- Subwoofer Level (dB): -15 dB to +15dB
Accessories
- Release keys: 2 pieces
- Escutcheon
- Installation Sleeve
- DC cord (Mitsumi to ISO): 15 cm
General Specifications
- Operating voltage: 14.4V (10.5 ~ 16V Allowable)
- Maximum Current Consumption: 10A
- Dimensions (WxHxD): 182 x 53 x 158mm
- Weight, inclu. sleeve & escutcheon: 1.3 kg
- Operation Temperature Range: -10°C ~ 60°C
