Specifications
Key Features
- 4 x 50W Max output power
- 1 RCA Preout, 2,5V
- Full detachable faceplate
- Android MSC / AOA2 compatible
- MP3, WMA, WAV & FLAC playback
- Blue Key & White Display Illumination (LED)
- FM with RDS & AM tuner
- Easy Sound Enhancment features
General Features
- DIN Size: 1 DIN
- Detachable Faceplate
- Key Illumination: Blue
- Rotary Encoder & Control Knob
- Music Search function
- Accent key: Audio Control
- Back-up Memory: Radio presets
- Attenuator with Smooth Volume Return
- Digital Clock (24H)
- All-off Select (20/40/60 minutes)
- Built-in Connector: Molex 16 pin
- Firmware upgreadable
Display Features
- Display Type: Liquid Crystal Display (LCD)
- Display Layout: 13 characters/digits
- Display Illumination: White LED
- Dimmer Control: Manual / Set by Timer
- Dimmer Timer
- Brightness control: Display (32 steps)
- Demo Mode
- Menu text in selectable language: English, Spanish, Russian
- TAG Language Display: English, Spanish, Russian, Greek & Turkish
Cosmetics features
- Triangle Illumination: Red
- Key illumination: Blue
- Display illumination: White LED
- Front terminals dust cover
Tuner Features
- Radio Data System
- Radio Text Plus
- Traffic Information
- FM Reception
- AM (MW/LW) Reception
- AF Regional: Selectable: AF/AF Reg/OFF
- Local search
- Auto TP search
- Presets: 24 Presets (18FM / 3LW / 3MW)
- Mixed preset memory (FM & AM): 6 presets
- Automatic Memory Entry (AME)
- Tuning mode (Auto1 / Auto2 / Manual)
- FM Stereo / Mono Selector
- Preset memory w/o back-up power
- Enhanced Other Networks Function (EON)
CE_Playable Audio file
- MP3 files are playable from: CD/USB
- WMA (.wma) files are playable from: CD/USB
- WAV (.wav) files are playable from: USB
- FLAC files are playable from: USB
CD Features
- Compatible with Kenwood Music Editor Lite
- CD Text with special Character Support: English, Spanish, Russian, Greek, Turkish
- D.A.C. processing: 16 bit
- 0 bit Mute
USB Features
- USB Type: USB 1.1/USB 2.0 Full Speed
- Drive Change
- Kenwood Music Editor Lite Compatible
- Kenwood Music Control App for Android
- Android Open Accessory support (AOA): V 2.0
- Repeat/Scan/Random search
- Repeat / Random Play
- Resume play
- Time code display
- 1A current capability
Audio Features
- Maximum Output Power: 50W x 4
- MOSFET Power IC
- Auxiliary input: Front Mini-jack
- Pre-out: 1 RCA
- Pre-out Output Level: 2.5V
- Preout Rear / Subwoofer Switchable
- Subwoofer Reference Level Adj.
- Tone Control / Easy EQ: 3-Band, 8 Presets
- Balance/Fader/Loudness Control
- Loudness Control: Off/Low/High
- Bass Boost Circuit: Off/+1/+2/+3
- Low-pass Filter
- Kenwood Sound Reconstruction
- Drive EQualizer
Connectivity
- Front USB & AUX Input
- DC-Cord: Molex to ISO
- Power Control (P.CON) wire
- 2-way (Tel/Navi) mute wire
- FM Antenna Input
Tuner Specifications
- FM range: 87.5Mhz - 108MHz (50Khz step)
- FM Usable Sensitivity: 0.71μV/75ohm (S/N 26dB)
- FM Quieting Sensitivity: 2μV/75ohm (S/N 46dB)
- FM Frequency Response: 30Hz ~ 15kHz (± 3dB)
- FM Signal to noise ratio (Mono): 64dB
- FM Stereo Separation (1kHz): 40dB
- MW range: 531kHz - 1611kHz (9kHz step)
- MW Usable Sensitivity: 28.2μV
- LW range: 153kHz - 279kHz (9kHz step)
- LW Usable Sensitivity: 50μV
CE_CODEC_Specs
- MP3 Format: MPEG 1/2 Audio Layer 3-Files
- WMA Format: Compliant with Windows Media Audio
- WAV Format: RIFF waveform Audio Format (only for LinearPCM)
- FLAC Format: all FLAC files
CD Specifications
- Laser Diode: GaAIAs
- Digital Filter(D/A): 8 Times Over Sampling
- Digital/Analogue Converter: 16 Bit
- Spindle Speed: 500 ~ 200rpm (CLV: 1 times)
- Wow & Flutter: below measurable limit
- Frequency Response: 20Hz ~ 20kHz (±1dB)
- Total Harmonic Distortion: 0.01% (1kHz)
- Signal to Noise Ratio: 105dB (1kHz)
- Dynamic Range: 90dB
- Channel Separation: 85dB
USB Specifications
- USB Version compatibility: USB 1.1/2.0 full speed
- File System: FAT 32/16/12
- Maximum Supply current: 1000mA
Audio Specifications
- Maximum Power: 50W x 4
- Output Power (DIN45324,+B=14.4v): 30W x 4
- Preout Level: 2500mV / 10kOhm,
- Preout Impedance: ≤ 600Ohm
- Speaker Impedance: 4Ohm ~ 8Ohm
- AUX Frequency Response: 20Hz ~ 20kHz (±1dB)
- AUX Maximum Input Voltage: 1000mV
- AUX Input Impedance: 30kOhm
- Bass Tone Control: 100Hz ±8dB
- Middle Tone Control: 1kHz ±8dB
- Treble Tone Control: 12.5kHz ±8dB
- Subwoofer Level (dB): -15 dB to +15dB
Accessories
- Release keys: 2 pieces
- Escutcheon
- Installation Sleeve
- DC cord (Molex to ISO): 25 cm
- Multi-Language Instruction Manual Included: Quick-Guide
- Manuals Downloadable
General Specifications
- Operating voltage: 14.4V (10.5 ~ 16V Allowable)
- Maximum Current Consumption: 10A
- Dimensions (WxHxD): 182 x 53 x 159mm
- Weight: 1300gr
- Operation Temperature Range: -10°C ~ 60°C
