GZRC 165AL-IV

€210,00
SKU
 Features


 - High quality 2 way component system
 - Klippel® optimized midwoofer with aluminum cone
 - Nomex spider
 - Copper cap for impedance linearizing
 - Resonance free steel basket
 - 1" titanium dome tweeter with slant tweeter housing
 - Separated tweeter and midwoofer 12dB crossovers for easy install

  Technical data



Model
GZRC 165AL-IV
Type
2 Wege Komposystem / 2 Way compo
Diameter of midwoofer or midrange
165 mm / 6.5"
Mounting diameter of midwoofer or midrange
142.5 mm / 5.61"
Mounting depth of midwoofer or midrange
68 mm / 2.68"
Voice coil of midwoofer or midrange
25 mm / 1"
Cone of midwoofer or midrange
Aluminum
Dustcap / Phaseplug of midwoofer or midrange
Aluminum
Basket of midwoofer or midrange
Euro-Din steel GZ basket
Magnet of midwoofer or midrange
Ferrit
Diameter of tweeter
49.5 mm / 1.95"
Mounting diameter of tweeter
44 mm / 1.73”
Mounting depth of tweeter
10 mm / 0.39"
Voice coil of tweeter
25 mm / 1"
Cone of tweeter
Titanium
Housing of tweeter
Machined aluminum
Magnet of tweeter
Neodymium
Power handling WRMS
120
Power handling W peak
190
Impedance
3 Ohm
SPL
89 dB (Mid) / 92 dB (Tw)
Frequency response

35 Hz - 4 kHz (Mid) / 3 - 26 kHz (Tw
